AVALON PLASTIC
CARD PRINTER
|
 |
Magicard Avalon entry level ID card printer.
If you want to print quality cards, again and
again and again, then the Magicard Avalon is for you. The
Avalon features our patented Holokote & Holopatch card
security which protects your cards against unauthorized
copying, 100 card capacity input hopper for batch printing,
and competitively priced high-quality color and monochrome
ribbons. |
|
|
|
 |
Holokote is an anti-copying watermark across the
entire card surface, that becomes visible when the card is
viewed at an angle. There is no additional cost involved in
printing Holokote cards. With the Avalon, a standard 'globes'
pattern is printed.
|
 |
Holopatch works with Holokote to produce a
highly-visible gold seal on the card, printed using special
card stock.
|
 |
High quality 300dpi image, printed right to the
edge of the card in 35 seconds.
|
 |
Avalon 105 : Includes built-in Magnetic Stripe
card encoder.
|
Consumables |
 |
Drop in ribbon
Simple drop-in ribbon comes in 250 shot color, 350
shot colour, or 1000 shot monochrome (black, red, blue, green, gold,
silver or white) types.
|
Avalon 100 Color ID Card Printer |
|
Print Speed |
Prints a full color edge-to-edge image in 35 seconds,
and a monochrome image in 6 seconds. |
|
Card security |
The user can choose whether to print a HoloKoteâ„¢
anti-copying watermark across the entire face of card. When used
with HoloPatchâ„¢ cards, one area of the HoloKoteâ„¢ watermark is
highlighted as a high visibility security seal. |
|
Warranty |
1 year limited warranty. |
|
Data Interface to PC |
USB rev1.1 (USB 2.0 compatible). |
|
Software drivers |
Windows 98, WindowsME, 2000, XP (all supplied with
printer). |
|
Dyefilm types |
AV1: Full color, resin black, & overcoat (YMCKO)
250 shots per roll (Part No. M9006-566).
LC1: YMCKO 5 panel dye
film 350 shots per roll (Part No. M9005-751).
LC3 : Monochrome
resin black 1000 shots per roll.
Range of color ribbons (red,
blue, green, gold, silver or white) 1000 shots per roll. |
|
Card types |
Prints on all standard PVC ISO CR80 sized cards.
HoloPatchâ„¢ cards available. |
|
Card thickness |
0.015" to 0.063" (0.38mm to 1.6mm). |
|
Card capacity |
100 cards feed hopper, 50 cards output
stacker. |
|
Printhead |
300dpi field replaceable. |
|
Power Source |
Internal power supply 90-265V 47-63Hz
autoranging. |
|
Dimensions |
7.5ins L x 7.9ins W x 8.7ins H (445mm L x 200mm W x
220mm H). |
|
Weight |
15.8lbs (7.2kg). |
|
Color |
Metallic Silver/Purple |
|
Operating Environment |
Sheltered Office environment 50ºF to 85ºF (10ºC to
30ºC).
|
|
Avalon 105 Color ID Card Printer
(Mag)
|
|
Print Speed |
Prints a full color, edge-to-edge image and
magnetically encodes and verifies HiCo magnetic stripe in around 40
seconds. |
|
Card stock types |
HiCo magnetic stripe PVC ISO CR80 sized cards.
HoloPatchâ„¢ magnetic stripe cards available.
|
|
|
| |
